• ORTECO 1000HD PILEDRIVER
• 1000 JOULES HAMMER
• AUTOMTAIC VERTICALITY

• Max. potential energy 48 kNmBlow rate at max. stroke 40 bl/min
• Max. stroke 1200 mm

• Centrifugal force (kN) : 450
• Eccentric moment (Nm) : 69
• Frequency (rpm) : 2 460
• Amplitude (mm) : 12
• Weight (kg) : 1 265
• Pressure needed (bar) : 350

• Impact power (kg/m) : 615
• Air flow needed (l/min) : 11 000
• Air pressure needed (bar) : 8

• Impact power (kgm) : 242
• Air flow needed (l/min) : 7 000
• Air pressure needed (bar) : 8
• Hammer weight with standard guide (kg) : 850

Final price is depending of the guide, completly overhauled (with same warranty than new) or condition as is !

• Total weight with clamp : 2500 kg
• Ram weight : 720 kg
• Stroke (max.) : 0 - 230 mm
• Blow rate/m : 150 - 190
• Recommended pulling force : 25 T / 40 T
• Air fl ow required at 7bars : 10 m3/minutes

• 1 new remote control
• 1 new monitoring system

• 1 spreader plate with can for 813 mm tubes maxi.

• 1 spreader and legs for drive standard sheetpiles

• Max. pile length 26 m
• Hammer size 7 ton
• Capacity hammer winch 80 ton
• Capacity pile winch 13 ton

Specifications

• Max. pile length 26 m
• Hammer size 7 ton
• Capacity hammer winch 80 ton
• Capacity pile winch 13 ton
• Capacity aux. winch 5 ton

• Impact energy : 24 kNm
• Blows/min : 80 mini -120 max.
• Weight : 7 tons

• Impact energy : 30 kNm
• Blows/min : 50 max.
• Weight : 4,1t
• Length : 5060mm
• Powerpack engine : Perkins T4236

• Max. potential energy 206/235 kNm
• Blow rate at max. stroke 30 bl/min
• Max. stroke 1.500 mm

• OPERATING WEIGHT 43 t
• LEADER LENGTH - (Effective Length) 12.5m - (15.5m)
• CAPACITY HAMMER INCLUDING CAP PLUS PILE 12t
• MAX. HAMMER WEIGHT 6t
• MAX. PILE WEIGHT 6t
• MAX. PULL 20t

• Max. potential energy 28 kNm
• Blow rate at max. stroke 60 bl/min
• Max. stroke 800 mm

• Max. potential energy 84 kNm
• Blow rate at max. stroke 40 bl/min
• Max. stroke 1.200 mm

1.Vibrodriver

• eccentric moment: 200 m.kg
• hydraulic power:709KW
• oil flow:1182 l/min.
• frequency: 23Hz/1380rpm

Vibro hammer type: high frequency with variable moment
Excentric moment: 0-16 kgm
Max. centrifugal force: 0-928 kN

• Excentric moment : 27 kgm
• Frequency : 1700 tr/mn
• Centrifugal force : 870 kN
• Weight : 4 980kg (without clamp)

• Weight base machine 51 ton
• Capacity hammer winch 12 ton
• Capacity pile winch 12 ton
• Capacity aux. Winch - ton
• Diesel engine Caterpillar C-7
• Output diesel engine 250/184 HP/kW
