PVE 25M Standard frequency vibratory hammer set

The unit is in very good condition and is provided with 3 months warranty on parts.
Starting procedure on site is possible on request.

This free handling vibrator is perfect for the VIBRATORY PILE DRIVING and EXTRACTION of profiles (sheet piles, tubes, H piles, etc.)

plus
Equipment :

PVE 25M Vibratory hammer

PVE 480 Powerpack

Year of manufacture : 2002
Counter hours : 3100 (approx. 1/3 at max rate)
Price excl.taxes : On request
Location : Avrillé (49) - France
Technical details :
  • Excentric moment : 27 kgm
  • Frequency : 1700 tr/mn
  • Centrifugal force : 870 kN
  • Weight : 4 980kg (without clamp)
More details
Option :
  • 1 used tube clamp set 2 x 55T: 20 000 € H.T. (mini 280mm, max 1844mm) + T bar
  • 1 used sheetpile clamp PVE 110T: 15 000 € H.T.



Technical details :

1 VIBRATORY HAMMER PVE 25M N°42

  • Excentric moment : 27 kgm
  • Frequency : 1700 tr/mn
  • Centrifugal force : 870 kN
  • Weight : 4 980kg (without clamp)
  • Hoses set : 32 meters

1 Powerpack PVE 480 N°49 – 3100 working hours approx. (1/3 at full rate)

  • Engine : Volvo
  • Power : 294 kW / 400 CV
  • Weight : 5500 kg

With wireless remote control + wire remote control 20 meters + control panel

Download documentation

Technical datas
