PAJOT Air impact hammer 600kg (MAP600)

This hammer is highly efficient pile driving machines used for PILE DRIVING a variety of profiles (sheet piles, tubes, H piles or wooden pile) when constructing retaining walls, special foundations, civil engineering structures and carrying out roadworks: sheet pile curtain walls, king post walls, etc.

Plug & Play ! You have to just connect the hammer to an air compressor and you can work immediatly...

NO ELECTRICITY - NO ELECTRONIC - NO HYDRAULIC LEAK

Equipment :

Air impact hammer PAJOT 600

Year of manufacture : 2009 (overhauled in 2015)
Counter hours : NA
Price excl.taxes : On request
Location : Avrillé (49) - FRANCE
Technical details :
  • Impact power (kgm) : 242
  • Air flow needed (l/min) : 7 000
  • Air pressure needed (bar) : 8
  • Hammer weight with standard guide (kg) : 850

Final price is depending of the guide, completly overhauled (with same warranty than new) or condition as is !

Option :

Sheetpiles, tubes, H beam guide available.

Technical details :
  • Impact power (kgm) : 242
  • Air flow needed (l/min) : 7 000
  • Air pressure needed (bar) : 8
  • Hammer weight with standard guide (kg) : 850

Final price is depending of the guide, completly overhauled (with same warranty than new) or condition as is !

The advantages of pneumatic impact hammers

  • Longevity, easy handling, low maintenance and operating costs.
  • Compactness allied to minimal weight
  • High impact rate and extremely powerful impact force
  • Adjustable force and rate
  • Capable of driving piles into all types of soil such as hardpan, marl, clay and shaly soil
  • For pile driving all available types of profile
  • They will work with any compressor with an adequate power rating
  • Automatic greasing via simple line greaser
  • Noise-proof covers are available for all impact hammers
